ROLAND V-STAGE 88 STAGE KEYBOARD

4 independent sections with Roland modelling technology: Organ, Acoustic Piano, Electric Piano and Synthesizer

Each section with its own mixer and button for split point for transposition

Organ section with 3 layers, 4 organ types (virtual tone wheel, 2x transistor, pipe organ), overdrive and rotary speaker effect

Piano section with V-Piano sound generation

Electric piano section with SuperNATURAL sound generation, 4 models (Tine, Reed, Digital Piano, Clavinet) and effects such as chorus, phaser, wah, tremolo and amp simulation

Synthesizer section with ZEN Core Engine, 2 parts, more than 400 sounds and support for SDZ Sound Packs and Roland Model Expansions

Effects section with delay, reverb and multi-effects

Master compressor and EQ

Pitch and modulation wheel

Drawbar with LED display and controls for all important parameters

4.3″ Graphic display

[Update] Here is more detail about rear panel connections:

PEDAL (1/4″ jacks): HOLD/R, CTRL 3/C, CTRL 2/L CTRL 1

MIDI (5-pin jacks): IN, OUT1, OUT2/THRU

USB: COMPUTER (Type-C), MEMORY (Type-A)

EXTERNAL device (USB Type-A): DEVICE 1, DEVICE 2

MIC INPUT (XLR jacks)

LINE INPUT (1/4″ jacks): R, L/MONO

SUB OUT BALANCED (1/4″ jacks): R, L

MAIN OUT BALANCED: R, L/MONO (1/4″jacks), R, L (XLR jacks)

Stereo PHONES (1/4″ jacks)
